Mobile (mobile) Hydraulic Ramps

The price varies according to different tonnage and features. Please get price.

It can be manufactured as tarpaulin/closed, high barrier, full galvanized, electric motor controlled according to the needs.

According to your color preference (Grey / yellow / blue orange / burgundy) colors can be produced.
Technicial Specifications
 Loading Capacity; It is produced in 8,000 kg / 10000 kg /12- 15-20 and higher carrying capacities.

Working Level: Our standard system works from 900 to 1600 mm. Between 900 mm and 1600 mm. It is manually raised and lowered with a pump on hydraulic feet. The system working in different sizes can be adjusted according to customer requirements.
 The mobile ramp has side barriers to increase safety
 Tongue fixed to the 40 cm long eyelet for safe loading on the front of the ramp.
 There are 2 wheels that enable the ramp to be transported effectively.
 Lifting/lowering operations are done with a specially designed manual hand pump. Optionally, it can be made in an electro-hydraulic controlled system. Thus, the ramp height can be adjusted electrically.
 There is a reinforced galvanized grating on the main body of the mobile ramps. (This structure prevents the forklift wheels from damaging the ramp and provides a suitable ground for loading.
 The mobile ramp has tails that are hinged to the main body and reinforced with NPU iron.
 Mobile ramp folding rear tails are reinforced with NPU and galvanized grille.
 The mobile ramp has 2 heavy-duty wheels with the dimensions of 300x70 and a carrying capacity of 3000 kg. When the ramp load is put on the wheels, the ramp is carried by these wheels.
 Our mobile ramps are approved by TPI .Patent ID: TR 2006 07571 Y and comply with EEC Directives 93/68 / EEC and 2006/42 / EC.
 Dimensions for standard product are below.
Its total length is 12 m. Total width is 2.4 m from the outside side by side and 2.1 m from the inside. is

 Our system is designed as heavy-duty, multi-shift use or 24/7 operation. The system is designed for robust and durable products.

INCLINE: 17 - 11 degrees. It has less inclination compared to jacked ramps. Hydraulic ramps have less slope. This gives hydraulic ramps an advantage when slope is important during loading and unloading.
