Rubber Belt Tumblast Shot Blasting Machine
| Price : | Ask For Price |
| Ad Code : | M-238372 |
| Ad Type : | For Sale - New |
| Views : | 694 |
| Date Updated : | 16 Jun 2025 |
| Production Type : | Special Production |
Poslu Makina Sanayi ve Ticaret Ltd.Şti.
Türkiye - Konya - Karatay
BÜSAN 4.ORGANİZE SANAYİ MİLENYUM CD.10723 SK NO:3 KARATAY/KONYA/TÜRKİYE
Rubber Belt Tumblast Shot Blasting Machine Ad Description
Field of Usage
For surface preparation by roughening before the painting or rubber coating on the pressed sheets metal, for removing the oxide layers after the hot forging, for surface revisioning of the weared parts, for surface cleaning of alu die cast parts and forged brass parts, for eliminating the tension of springs.
| Description | Unit | LTK-1 | LTK-3 |
|---|---|---|---|
| Drum Capacity | kg | 150 | 300 |
| Max Weight of Parts | kg | 15 | 30 |
| Diameter of Drum | mm | 650 | 1000 |
| Length of Drum | mm | 900 | 1000 |
| Number of Turbines | pcs | 1 | 1 |
| Turbine Motor / Rotation | kW / rpm | 5.5 / 3000 | 7.5 / 3000 |
| Number of Blades | pcs | 8 | 8 |
| Turbine Granular Flow | kg/min | 180 | 180 |
| Drum Turning Motor | kW | 0.75 / 1500 | 1.5 / 1500 |
| Elevator Motor | kW | 0.75 / 1500 | 0.75 / 1500 |
| Filter Capacity | m³/h | 2500 | 5000 |
| Fan Power | kW | 3 | 7.5 |
| Width of the Machine | mm | 1300 | 1500 |
| Depth of the Machine | mm | 1500 | 1750 |
| Height of the Machine | mm | 2100 | 3750 |
