HANGER TYPE SHOT BLASTING MACHINES: EXCELLENCE IN INDUSTRIAL SURFACE PREPARATION

Hanger Type Shot Blasting Machines play a strategic role in modern manufacturing and surface preparation processes. They are specifically engineered for cleaning, descaling, or preparing surfaces of workpieces that are too large, heavy, fragile, or complex in geometry to be processed in standard tumble-style machines. These systems ensure the necessary surface roughness (such as the Sa 2.5 standard) prior to coating, painting, or welding, thereby elevating the final product quality to the highest international standards.

Advanced Operating Principle and Engineering Details

The operation of the machine is based on an abrasive cycle that penetrates every point of the workpiece equally. The process begins by loading the workpieces onto high-capacity rotating hooks (hangers) integrated into a rail system. Once these parts enter the blasting chamber, they are continuously rotated 360 degrees around their own vertical axes.

High-performance turbines, strategically positioned at specific angles within the cabinet, hurl abrasive media—such as steel shot or grit—at the rotating parts at high velocities using centrifugal force. The combination of the workpiece's rotation and the multi-directional throwing angles of the turbines ensures that even the most complex contours, recesses, and holes are thoroughly cleaned without any "blind spots." This synchronized operation is the key to achieving a perfectly homogeneous surface profile.

Strategic Application Areas and Sectoral Solutions

Thanks to its versatility, hanger-type shot blasting systems are a critical touchpoint in almost every branch of heavy industry:

• Automotive and Heavy Machinery: Surface cleaning of chassis components, axles, and engine parts, as well as shot peening operations to increase resistance against metal fatigue.

• Steel Construction: Removal of rust and welding residues from beams, columns, and massive welded structures to enhance paint adhesion.

• Foundry and Forging Industry: Rapid removal of core sand and oxide layers from engine blocks and gearbox housings.

• General Metal Fabrication: Burring, descaling, and surface finishing of all medium-to-large scale parts, from crane components to agricultural machinery.

Technical Advantages and Operational Efficiency

These machines are not merely cleaning tools; they are intelligent systems that optimize operational costs:

1. High Loading Capacity: Hook systems can be scaled starting from 500 kg up to 5 tons or more depending on requirements, allowing heavy workpieces to be processed safely.

2. Superior Material Durability: The inner surfaces of the blasting chamber are lined with Manganese Steel armor plates to withstand the destructive impact of abrasives. This lining extends the operational life of the machine and minimizes maintenance costs.

3. Closed-Loop Recycling System: Used abrasives are automatically transported back to the separator via a screw conveyor and elevator system. Here, dust and broken particles are filtered out; clean abrasive is returned to the system. This cycle significantly reduces raw material consumption.

4. Smart Control (PLC): Advanced PLC systems (such as Siemens) allow for digital management of turbine speeds, blasting durations, and rotation parameters. This ensures repeatable quality and minimizes operator error.

5. Occupational Health and Environmental Approach: High-capacity Jet-Pulse filter units vacuum the dust generated during operation, keeping the atmosphere and working environment clean. The fully enclosed cabinet structure maximizes occupational safety standards.

Please contact us to see our value-added solutions on-site, receive more technical information, or visit our facility.
