Quantity Transfer Printing Machine TM-1800 / TC-320

TECHNICAL SPECIFICATIONS OF TM-1800 / TC-405 TRANSFER PRINTING MACHINE

• Working Width is 1800 mm
• Cylinder Diameter is 405 mm
• Heating System is Closed Circuit Oil Heated.
• Working Speed 200 - 350 meters per hour. production between
• Max. Electric Power 23 Kw electric power (Three-phase) 380 V 50-60 Hz
• Continuous Consumption Average 12 Kw hour electricity consumption.
• Pressure System Max. 6 Bar air pressure
• Drives AC Inverter
• Fabric Winding System Tension and Potency Speed Adjustable
• Felt is 100% Nomex
• Net Weight 1555 Kg.
• Area covered
• Width 1400mm
• Length 2800mm
• Height 1350mm
• The Machine is Double Motorized.
• Protective Paper Insert and Wrapper
• The machine reaches 230 C 70 minutes after it is turned on.
• For safety, the master cylinder can run backwards.
• There is a Scraper Tape for safety and stripping the fabric.
• It has an automatic felt centering system.
• It has a Felt Cooler Fan.
• The usable width of the machine is 1800 mm.
• The Cylinder has a manual turning handle to be used in case of power failure.
• At the entrance of the machine, there is a safety wire for emergency stop and a barrier that prevents hand pinching on the cylinder.

OPTIONAL APPARATUS

• Air Shaft
• Fabric Cooler Fan
• Extra Paper Ball Attachment from the Top
• Protective Paper Tension Shaft
• Protector
