Helical Wire Weaving Machine
| Price : | Ask For Price |
| Ad Code : | M-451454 |
| Ad Type : | For Sale - New |
| Views : | 214 |
| Date Updated : | 23 Jun 2025 |
| Production Type : | Brand |
| Brand : | Arm Telcibey |
| Model : | Hto Pro |
| Production Year : | 2025 |
1
year
year
Türkiye - Ankara - Beytepe
Beytepe Mah. 1669/3 Sokak No:10
Helical Wire Weaving Machine Ad Description
Helical Wire Weaving Machine – ARM Telcibey – HTO PRO
| Model | Weaving Width | Wire Diameter | Mesh Size | Machine Weight | Dimensions (m) | Power |
|---|---|---|---|---|---|---|
| HTO-200 | 0.2–2.2 m | 1.9–3.2 mm | 30–85 mm | 1800 kg | 3×1.3×1.4 | 5.5 kW |
| HTO-300 | 0.2–3.2 m | 1.9–3.2 mm | 30–85 mm | 2000 kg | 4×1.3×1.4 | 5.5 kW |
| HTO-400 | 0.2–4.2 m | 1.9–3.2 mm | 30–85 mm | 2200 kg | 5×1.3×1.4 | 5.5 kW |
| HTO-600 | 0.2–6.2 m | 1.9–3.2 mm | 30–85 mm | 2750 kg | 7×1.3×1.4 | 5.5 kW |
Main motor: 3 kW x 3000 rpm Servo
Capacity: up to 120 m²/hour (varies by mesh size)
Wire Strength: 450–500 Nw/mm²
Mould Options: 2 types (customizable)
