Servo Grass Fence Weaving Machine (Tls-100)

SERVO GRASS FENCE WEAVING MACHINE (TLS-100)

The Servo Grass Fence Weaving Machine, developed for the production of grass wire fences, is an ideal machine for professional manufacturers with its high production capacity and ease of use features. The driver and touch screen controlled system allows the production process to be easily managed and desired dimensions to be quickly adjusted.

The machine ensures safe operation with an automatic stop and alarm system in cases such as wire entanglement or production completion. Thanks to the electronic speed control system, the production speed can be adjusted by the operator to the desired level. With its practical mold change system and user-friendly design, production processes are carried out quickly and efficiently.

Technical Specifications

Machine Type: TLS-100
Weaving Width: 20 – 220 cm
Production Capacity: 30 – 55 m² / hour (42 – 55 eyes)
Eye Spacing (Grass): 42x42 – 55x55
Wire Thickness: 1.5 mm – 2.5 mm
Control System: Driver / Touch Screen
Electric Power: 3 KW
Machine Weight: 800 Kg

Machine Dimensions

Height: 250 cm
Width: 200 cm
Length: 380 cm

Machine Features

• Maximum dimensions are entered from the screen; the machine automatically stops and alarms at the end of the job.

• There are 2 separate stop systems in case of wire entanglement.

• Operation at desired speed with electronic speed control knob.

• Easy use with manual and semi-automatic operation options.

• Minimum weaving width is 20 cm.

• System developed for practical mold change and ease of use.

• Operates with 380V electricity.

• 24-hour continuous operation capability.

• Single input system.

• Operable by a single operator.

• Warranty: 2 years excluding user errors.
