The Wiesser MV1000P CNC Vertical Machining Center offers a remarkable solution in metalworking. Designed with a Japanese-inspired, wide and rigid body structure, this machine ensures stable operation. Equipped with the Big Plus BBT-40 Direct Motor, it guarantees precise and high-quality processing. The robust design includes greased, wide, dual-row roller linear guides that maintain integrity across 17 distinct points. This machine is optimized for high speed and precision, enabling superior surface quality and equipping you for various tasks with ease. It's outfitted with features like rigid tapping, a 24-station arm-type automatic tool changer, and multiple cooling systems, making it an exceptional choice for demanding CNC milling tasks.
|
Technical Specifications |
|
|
Table Dimensions |
1200 x 600 mm |
|
Table Load Capacity |
900 kg |
|
X*Y*Z Axis Travel |
1020 * 610 * 610 mm |
|
Distance between Spindle Nose and Table |
100 ~ 710 mm |
|
Distance from Spindle Center to Column |
628 mm |
|
Spindle Motor Power |
15 kW |
|
Spindle Taper |
BBT-40 / Big Plus |
|
Max Spindle Speed |
12,000 rpm |
|
Spindle - Motor Transmission Type |
Direct Drive |
|
Automatic Magazine Type / Station Count |
Arm Type / 24 stations |
|
Max Tool Diameter |
With full side pots: 90 mm / Empty side pots: 180 mm |
|
Max Tool Length / Weight |
300 mm / 8 kg (for 24-tool magazine) |
|
Linear Roller Guide (X Axis Type and Width) |
35 mm |
|
Linear Roller Guide (Y & Z Axis Type and Width) |
45 mm |
|
Ball Screw Diameter X*Y*Z / Class |
45*45*45 mm / C2 Class |
|
Axis Motor Powers X*Y*Z |
3*3*4.5 kW |
|
Rapid Feed X*Y*Z |
36*36*36 m/min |
|
Cutting Feed X*Y*Z |
25 m/min |
|
Positioning Accuracy |
±0.005 mm |
|
Repeatability Accuracy |
±0.003 mm |
|
Machine Dimensions W*D*H |
2528 * 2763 * 2843 mm |
|
Approximate Machine Weight |
7,300 kg (may vary with options) |
