Voltage Relıef Wıth 40Kw Aır-Cooled Inductıon Machıne and Flexıble Inductıon Heatıng Cable
Price :
Ask For Price
Ad Code :
M-379063
Ad Type :
For Sale - New
Views :
830
Date Updated :
26 Apr 2024
Production Type :
Brand
Brand
Taıpan Induction
Model :
ALBAHEAT40
Production Year :
2024
10
year
year
İNDMAKİNA DIŞ TİC. VE SANAYİ LTD.ŞTİ.
Türkiye - İstanbul - Ümraniye
Dudullu Organize Sanayi Bölgesi Mah.,
Des Sanayi Sitesi,116.Sok.C22 Blok, No:49
34775 Yukarı Dudullu-Ümraniye/İSTANBUL
Ad Description
The large-dimensional symmetrical or non-symmetrical business parts can be heated to the voltage removal at the same time as well as at the same time from welding or after welding.
http://www.induksiyonmakinalari.com
With 40KW Air Cooled Induction Machine and Flexible Induction Heating Cable, Coupling Removal, Bearing Removal, Shaft Removal, Tight Roller Removal, Pre-Welding and Post-Welding Stress Relief Operations Can Be Performed.
PURPOSE OF USAGE:
Apart from pre-source and post-source voltage, it can also be easily removed by heating or heating with special inductors, such as 40kw air-cooled induction machine and FLEXIBLE induction heating cable, with special inductors, such as bearings-couplings or special inductors according to the workpieces.
TECHNICIAL SPECIFICATIONS:
-Output Power: 40KW
-Output Frequency: 15-25KHz
-Air Cooled / With Fan
-380V +- 10% , 50/60Hz
-Temperature Control Unit, which can be set to the desired temperature,
-Min.400°C High Temperature Resistant, Flexible Induction Heating Cable – 40 meters
-Optional: Plug-in Inductor or Inductors made according to the dimensions of the workpieces used continuously, according to the customer's request.
-High Temperature Ceramic Fiber Insulation Material For Cable Protection
-INDUCTION OUTPUT POWER: 40KW
-OUTPUT POWER CAN BE ADJUSTED TO REMOVE WORKPIECES SUCH AS BEARINGS OR COUPLING WITH DIFFERENT OUTER DIAMETERS, BY INDUCTION HEATING,
-INDUCTION HEATING POWER CONTROLLED ACCORDING TO THE WORKPIECE SIZE FROM THE FRONT PANEL,
-MAIN SWITCH FOR ENERGY ON-OFF ON THE FRONT PANEL FOR STARTING THE INDUCTION MACHINE, AMPERMETER, VOLTMETER, POWER SETTING SWITCH, TEMPERATURE CONTROL UNIT AND MISSING PHASE, OVERCURRENT, HIGH VOLTAGE VOLTAGE, WASTE VOLTAGE, WASTE VOLTAGE, WASTE VOLTAGE, WAVE
-40KW AIR COOLED INDUCTION MACHINE WITH BRAKE-WHEELED MOBILE UNIT (STANDARD) WHERE THE MACHINE, FLEXIBLE INDUCTION CABLE AND INDUCTORS CAN BE MOVED TO THE WORKPIECE TO BE REMOVED or ASSEMBLED
-AIR-COOLED FLEXIBLE INDUCTION HEATING CABLE OR WITH PLUG INDUCTOR, INDUCTION MACHINE INSTALLATION-COMMISSIONING-OPERATING AND DELIVERY-TRAINING, SERVICE AND WARRANTY SERVICES FIRM.
Stress Relief, Pre Weld Stress Relief, Post Weld Stress Relief, Large Size Part Stress Relief, Pipe Stress Relief, Kaynak Yeri Gerilim Giderme
