Vibrating Screen Systems 2-3-4 Layers 2 Years Warranty

Price : Ask For Price
Ad Code : M-445639
Ad Type : For Sale - New
Views : 10
Date Updated : 12 Jul 2024
Production Type : Special Production
Brand : Constmach
Model : Titreşimli Elek
Production Year : 2024
1
year
CONSTMACH Konkasör Tesisi ve Beton Santrali
Türkiye - İzmir - Kemalpaşa
Halilbeyli Bayosb Anadolu Cad. No:1 Bağyurdu Organize Sanayi Bölgesi Kemalpaşa / İzmir / TÜRKİYE
Ad Description

For Sale: Vibrating Screen System - Contact Us 24/7

Our vibrating screen systems combine high performance and durability to make your production processes more efficient. Our models, including CVS-1240, CVS-1640, CVS-1650, CVS-1850, CVS-2050, CVS-2060, and CVS-2470, offer options with different layer numbers and sizes to suit your needs. Each model provides maximum efficiency with 2 to 4 layers and high production capacities.

Our vibrating screen systems offer production capacities ranging from 70 t/h to 336 t/h to meet all your production needs. For example, our CVS-1240 model, with layers measuring 1,200 x 4,000 mm, has a production capacity of 70-95 t/h and operates with just a 7.5 kW motor. Other models offer higher capacities and different motor powers. Notably, the CVS-2470 model, with layers measuring 2,400 x 7,000 mm and dual motor power, can produce up to 336 t/h.

Each of our vibrating screen systems offers long-lasting use with their durable structures and high capacities. They are robust and reliable, with weights ranging from 7,400 kg to 24,000 kg. They increase your production capacity while reducing costs with high efficiency and low energy consumption.

Our vibrating screen systems can quickly and effectively screen all types of materials. They are designed to optimize production processes, increase efficiency, and reduce costs. Each model offers flexible solutions with various layer options and production capacities. Our products combine superior engineering and innovative design to deliver the best results. Make a difference in your production processes with our vibrating screen systems.

CVS-1240 Model Vibrating Screen Technical Specifications

Layer Number: 2

  • Layer Dimensions: 1,200 x 4,000 mm (4.8 m²)
  • Production Capacity: 70 – 95 t/h
  • Motor Power: 7.5 kW
  • Weight: 7,400 kg

Layer Number: 3

  • Layer Dimensions: 1,200 x 4,000 mm (4.8 m²)
  • Production Capacity: 70 – 95 t/h
  • Motor Power: 11 kW
  • Weight: 7,700 kg

Layer Number: 4

  • Layer Dimensions: 1,200 x 4,000 mm (4.8 m²)
  • Production Capacity: 70 – 95 t/h
  • Motor Power: 11 kW
  • Weight: 8,000 kg

CVS-1640 Model Vibrating Screen Technical Specifications

Layer Number: 2

  • Layer Dimensions: 1,600 x 4,000 mm (6.4 m²)
  • Production Capacity: 100 – 130 t/h
  • Motor Power: 11 kW
  • Weight: 13,500 kg

Layer Number: 3

  • Layer Dimensions: 1,600 x 4,000 mm (6.4 m²)
  • Production Capacity: 100 – 130 t/h
  • Motor Power: 15 kW
  • Weight: 14,000 kg

Layer Number: 4

  • Layer Dimensions: 1,600 x 4,000 mm (6.4 m²)
  • Production Capacity: 100 – 130 t/h
  • Motor Power: 15 kW
  • Weight: 14,750 kg

CVS-1650 Model Vibrating Screen Technical Specifications

Layer Number: 2

  • Layer Dimensions: 1,600 x 5,000 mm (8 m²)
  • Production Capacity: 130 – 160 t/h
  • Motor Power: 11 kW
  • Weight: 14,000 kg

Layer Number: 3

  • Layer Dimensions: 1,600 x 5,000 mm (8 m²)
  • Production Capacity: 130 – 160 t/h
  • Motor Power: 15 kW
  • Weight: 14,750 kg

Layer Number: 4

  • Layer Dimensions: 1,600 x 5,000 mm (8 m²)
  • Production Capacity: 130 – 160 t/h
  • Motor Power: 18.5 kW
  • Weight: 15,500 kg

CVS-1850 Model Vibrating Screen Technical Specifications

Layer Number: 2

  • Layer Dimensions: 1,800 x 5,000 mm (9 m²)
  • Production Capacity: 140 – 180 t/h
  • Motor Power: 11 kW
  • Weight: 16,000 kg

Layer Number: 3

  • Layer Dimensions: 1,800 x 5,000 mm (9 m²)
  • Production Capacity: 140 – 180 t/h
  • Motor Power: 15 kW
  • Weight: 16,750 kg

Layer Number: 4

  • Layer Dimensions: 1,800 x 5,000 mm (9 m²)
  • Production Capacity: 140 – 180 t/h
  • Motor Power: 18.5 kW
  • Weight: 17,500 kg

CVS-2050 Model Vibrating Screen Technical Specifications

Layer Number: 2

  • Layer Dimensions: 2,000 x 5,000 mm (10 m²)
  • Production Capacity: 170 – 220 t/h
  • Motor Power: 15 kW
  • Weight: 16,500 kg

Layer Number: 3

  • Layer Dimensions: 2,000 x 5,000 mm (10 m²)
  • Production Capacity: 170 – 220 t/h
  • Motor Power: 18.5 kW
  • Weight: 17,400 kg

Layer Number: 4

  • Layer Dimensions: 2,000 x 5,000 mm (10 m²)
  • Production Capacity: 170 – 220 t/h
  • Motor Power: 22 kW
  • Weight: 18,200 kg

CVS-2060 Model Vibrating Screen Technical Specifications

Layer Number: 2

  • Layer Dimensions: 2,000 x 6,000 mm (12 m²)
  • Production Capacity: 192 – 240 t/h
  • Motor Power: 15 kW
  • Weight: 17,500 kg

Layer Number: 3

  • Layer Dimensions: 2,000 x 6,000 mm (12 m²)
  • Production Capacity: 192 – 240 t/h
  • Motor Power: 18.5 kW
  • Weight: 19,000 kg

Layer Number: 4

  • Layer Dimensions: 2,000 x 6,000 mm (12 m²)
  • Production Capacity: 192 – 240 t/h
  • Motor Power: 22 kW
  • Weight: 20,500 kg

CVS-2470 Model Vibrating Screen Technical Specifications

Layer Number: 2

  • Layer Dimensions: 2,400 x 7,000 mm (16.8 m²)
  • Production Capacity: 268.8 – 336 t/h
  • Motor Power: 2 x 15 kW
  • Weight: 20,500 kg

Layer Number: 3

  • Layer Dimensions: 2,400 x 7,000 mm (16.8 m²)
  • Production Capacity: 268.8 – 336 t/h
  • Motor Power: 2 x 18.5 kW
  • Weight: 22,000 kg

Layer Number: 4

  • Layer Dimensions: 2,400 x 7,000 mm (16.8 m²)
  • Production Capacity: 268.8 – 336 t/h
  • Motor Power: 2 x 22 kW
  • Weight: 24,000 kg
