Stro B - 4 Independent Axis
Price :
Ask For Price
Ad Code :
M-377001
Ad Type :
For Sale - New
Views :
286
Date Updated :
02 May 2024
Production Type :
Special Production
Model :
Stro B
2
year
year
Esp Mühendislik Cnc Kesim Makinalari
Türkiye - Bursa - Nilüfer
ODUNLUK MAH. LEFKOŞE CAD. NO:19 B BLOK EKER İŞ MERKEZİ, 16110 NİLÜFER/BURSA
Ad Description
Features:
- Ability to process G code data.
- Thanks to 4 separate stepper motors, X1 – X2 and Y1 – Y2 axes can be moved separately.
- Lengthening and shortening of the cutting wire according to the axis movements thanks to the special spring system.
- Automatically turn on the heat when the job starts, and automatically turn off the heat when the job is finished.
- Audible warning system at the end of the job. Visual (light) warning system and led lighting while the machine is running.
- Handy control panel and Computer.
- Drawings are prepared in Corel Draw. (Corel Draw is not included in the price.)
- WinPC-NC Economy and DevFoam Pro 2(toolpath) program are included in the price as licensed.
- Strong sigma profile aluminum body.
- Special cut and painted connection sheets.
Working (Cutting) Area:
- X1-X2 axis: 1200 mm.
- Y1-Y2 axis: 1000 mm.
- Wire Length Standard : 1000 mm.
Power Usage:
- 220 VAC 50/60 Hz. , 1.5 kW, 10 Amps.
Machine Dimensions:
- Machine: 190cm Length X 144cm Width X 190cm Height
- Weight: 50KG.
