Scottish-Type Coal Boiler, With Fan and Thermostat, Toki Boiler Without Fan
| Price : | Ask For Price |
| Ad Code : | M-157462 |
| Ad Type : | For Sale - New |
| Views : | 1328 |
| Date Updated : | 14 Nov 2025 |
| Production Type : | Brand |
| Brand : | AKTES Pazarlama |
| Production Year : | 2025 |
Aktes Pazarlama
Scottish-Type Coal Boiler, With Fan and Thermostat, Toki Boiler Without Fan Ad Description
Scotch Type Coal-Fired Boiler AKS
Scotch Type, Solid Fuel, Coal-Fired Cylindrical Three-Pass Hot Water Boiler AKS
Capacity Range: 60,000 – 800,000 Kcal/h
Scotch-type boilers are designed as three-pass flame and smoke tube systems. They have a versatile design suitable for all heating systems. The efficiency value determined by TSE is 80.5%. AKS boilers are solid fuel boilers with a grate surface designed to provide maximum efficiency. They have a fully cylindrical combustion chamber and are suitable for stoker systems. In addition to the capacities listed in the technical table, production can be made up to 5,000,000 Kcal/h with stoker and front furnace options.
AKS Type Solid Fuel, Coal-Fired Three-Pass Hot Water Boiler Technical Data Table
| Product Code | Thermal Power (kcal/h) | kW | L (mm) | D (mm) | H (mm) | ØD (mm) | Flow/Return Connection (DN) | Flow Safety (DN) | Return Safety (DN) | Approx. Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|---|
| AKS60 | 60,000 | 70 | 1650 | 1100 | 1250 | 200 | 50 | 25 | 20 | 595 |
| AKS90 | 90,000 | 105 | 1800 | 1190 | 1350 | 200 | 65 | 32 | 25 | 658 |
| AKS120 | 120,000 | 140 | 2000 | 1230 | 1400 | 250 | 65 | 32 | 25 | 998 |
| AKS150 | 150,000 | 174 | 2150 | 1270 | 1450 | 300 | 65 | 40 | 32 | 1350 |
| AKS180 | 180,000 | 209 | 2300 | 1460 | 1650 | 350 | 65 | 40 | 32 | 1640 |
| AKS210 | 210,000 | 244 | 2400 | 1510 | 1700 | 350 | 65 | 40 | 32 | 1882 |
| AKS240 | 240,000 | 279 | 2590 | 1600 | 1790 | 350 | 80 | 40 | 32 | 2025 |
| AKS270 | 270,000 | 314 | 2640 | 1600 | 1810 | 400 | 80 | 40 | 32 | 2355 |
| AKS300 | 300,000 | 348 | 2720 | 1710 | 1890 | 400 | 80 | 50 | 40 | 2530 |
| AKS330 | 330,000 | 383 | 2850 | 1780 | 2000 | 450 | 80 | 50 | 40 | 2616 |
| AKS360 | 360,000 | 419 | 2900 | 1830 | 2050 | 450 | 80 | 50 | 40 | 3058 |
| AKS390 | 390,000 | 453 | 2950 | 1870 | 2100 | 450 | 80 | 50 | 40 | 3446 |
| AKS420 | 420,000 | 488 | 3000 | 1900 | 2150 | 450 | 100 | 50 | 40 | 3930 |
| AKS450 | 450,000 | 523 | 3150 | 1925 | 2150 | 450 | 100 | 50 | 40 | 3980 |
| AKS480 | 480,000 | 558 | 3270 | 1950 | 2180 | 500 | 100 | 50 | 40 | 4120 |
| AKS510 | 510,000 | 593 | 3310 | 1970 | 2200 | 500 | 100 | 50 | 40 | 4280 |
| AKS540 | 540,000 | 628 | 3360 | 2010 | 2250 | 500 | 100 | 50 | 40 | 4380 |
| AKS570 | 570,000 | 663 | 3400 | 2090 | 2320 | 500 | 100 | 65 | 50 | 4640 |
| AKS600 | 600,000 | 698 | 3450 | 2160 | 2450 | 500 | 125 | 65 | 50 | 5230 |
| AKS700 | 700,000 | 814 | 3600 | 2200 | 2490 | 600 | 150 | 65 | 50 | 5705 |
| AKS800 | 800,000 | 930 | 3700 | 2300 | 2550 | 600 | 150 | 65 | 50 | 5890 |
The values in the table may vary by ±5%. We reserve the right to make changes to dimensions and models. Our company cannot be held responsible for printing errors in the measurements.
