The Powder Coffee and 3-In-1 Stick Coffee Packaging Machine is engineered to automatically wrap small to medium-sized boxes in square or rectangular shapes using a single piece or lined-up envelope type packaging model. Operate it easily through a user-friendly touch screen with various settings and controls managed via an encoder system PLC. This operator-friendly machine allows for straightforward mold changes. Feeding can be performed manually, or automatically in line with the boxes' production path. An opening band strip is attachable for easy access to outer wrapping. Optional features include a colored, printed outer wrapping with a photoelectric sensor system and date coding equipment.
| Machine Dimensions |
H190 x W100 x L430 cm |
| Weight |
950 Kg / 1.100 Kg |
| Feed Belt Dimensions |
H90-100 x W25-30 x L140-150 cm |
| Power |
3.5 kW, 380/400 VAC 3 Phase 50/60 Hz |
| Air Consumption |
6 bar/min |
| Noise Level |
70-80 Decibels |
| Capacity Per Minute |
20-40 units depending on product volume |
| Package Dimensions |
- Length (A): Min: 50mm / Max: 320mm
- Width (B): Min: 30mm / Max: 120mm
- Height (C): Min: 20mm / Max: 80mm
- OPP, BOPP, PVC Length: Min: 110mm / Max: 420mm
|
