Plastic Thermoforming Molding Machines
| Price : | Ask For Price |
| Ad Code : | M-432676 |
| Ad Type : | For Sale - New |
| Views : | 548 |
| Date Updated : | 06 Dec 2024 |
| Production Type : | Brand |
year
CMK 95/65-S4 4 STATİON THERMOFORMİNG MACHİNE
|
FORMING GROUP |
DIMENSIONS |
|
MAX FORMING AREA |
950 X 650 mm |
|
LOWER AND UPPER SERVO MOTORS |
7,5 KW |
|
LOWER AND UPPER FORMING HEIGHT |
150 mm |
|
FORMING UPPER RESISTANCE |
95 KW |
|
FORMING LOWER RESISTANCE |
76 KW |
|
MOVING NEEDLE BEARING |
|
|
FORMING GROUP TOTAL MOTOR POWER |
30 KW |
|
TOTAL HEATING POWER(During Runing) |
80-90 KW |
|
PUNCHING GROUP ( 4th Station ) |
|
|
MAX PUNCHING AREA |
980 X 680 mm |
|
LOWER AND UPPER PUNCHING HEIGHT |
150 mm |
|
SERVO LOWER AND UPPER SERVO MOTORS |
7,5 KW |
|
PUNCHING GROUP TOTAL MOTOR POWER |
18.1 KW |
|
CUTTING GROUP |
|
|
MAX CUTTING AREA |
980 X 680 mm |
|
LOWER AND UPPER SERVO MOTORS |
7,5 KW |
|
LOWER AND UPPER FORMING HEIGHT |
150 mm |
|
CUTTING GROUP TOTAL MOTOR POWER |
17.1 KW |
|
STACKING GROUP |
|
|
MAX STACKING AREA |
900 X 1500 mm |
|
STACKING SERVO MOTOR |
3 KW |
|
STACKING GROUP TOTAL MOTOR POWER |
4,11 KW |
|
GENERAL SPECİFİCATİON |
|
|
MACHINE SIZE L- H W |
12000 X 3500 X 2800 |
|
TOTAL WEIGHT |
12.000 KG |
|
TOTAL INSTALLED MOTOR POWER |
69 KW |
|
TOTAL HEATING POWER |
171 KW |
