PET bottle recycling line with hourly 1500-3000 Kg / S Capacity

The PET bottles that will enter the recycling system are separated manually from the foreign materials and PVC in the sorting conveyor. At this stage, the color separation of the bottles is also made. The loading conveyor feeds the PET bottles to the crushing machine on a regular basis. Crushing machine, PET material to be recycled, part size 10 - 12 mm. reduces. The crushing machine is sprayed with water from the upper chamber together with PET bottles and pre-washing the dirty bottles in the crushing machine. PET material is transported by the spiral screw geometry elevator located under the crushing machine. The crushing outlet elevator transports PET burrs to the Cover Label Separation Pool. In this pool, covers and labels are taken from the pool with the sprinklers on the water surface. At the bottom, the elevator mixes the PET burrs so that the caps and labels are separated (surfaced) and transports the material to the pool outlet. A second elevator at the pool outlet removes the burrs out of the pool. The elevator-separator located at the bottom of the pool separates water and dirt on the PET burrs and transports the material to the Chemical Washing Machine. In the Chemical Washing Machine, PET burrs are washed with water and chemicals at 90 degrees. This process removes both dirt on the material and glue residues used for gluing labels. Since the glue causes problems in areas where PET is used after recycling, it must be completely cleaned during recycling. Using a digital metering and dosing pump, chemicals are supplied to the washing machine automatically and the washing system operates continuously. The chemicals on the PET material coming out of the washing machine are neutralized by the digital metering dosing pumps in the Neutralization Unit. In this way, the water in the pool in the following section of the system can be used for a much longer time. In the second pool, both the PET burrs are rinsed and the remaining label and cover pieces are separated. The centrifugal separator then separates the water on the burrs
