Mobile Concrete Batching Plants
| Price : | Ask For Price |
| Ad Code : | M-271254 |
| Ad Type : | For Sale - New |
| Views : | 393 |
| Date Updated : | 26 Aug 2023 |
| Production Type : | Special Production |
| Brand : | ins makina |
| Model : | İNS MBS 100 |
| Production Year : | 2017 |
İns Makina Beton Santralleri
Türkiye - Ankara - Yenimahalle
Turgut Özal Mah. 1940. Cadde, No:81/31
Mobile Concrete Batching Plants Ad Description
100 m3 h Capacity
Mobile concrete batching plants
Technical Specifications
| Aggregate Bunker | : | Tanks: 4x15 m3 Total Volume : 60 m3 |
| Cement Silo | : | Capacity:100 tons –2 unit (can optionally be bolted) |
| Cement Spiral Conveyor | : | 2 Unit, Size : Ø 273 mm x 12000 mm WAM |
| Cement Silo Equipments | : | Upper and Lower Level Meters WAM |
| Aggregate Weighing Machine | : | 4 m3 Load cell : 4 x 5000 kg, ESIT |
| Transsit mikser loading band | : | Size: 1 Unit 1000x16000 mm. |
| Cement Weighing Tank | : | Weighing Capacity:1100 kg,Load Cell:1000 kgx3, ESIT,WAM |
| Water Weighing Tank | : | Weighing Capacity:700 kg,Load Cell:1000 kgx2, ESIT,WAM |
| Additive Tank | : | Weighing Capacity:50 kg ,Load Cell:100 kg , ESIT,WAM |
| Air Valves Board | : | MAG, Compressr 500 LT Volume, |
| Concrete Plant Automation | : | Tekno Automation |
|
Silo Top Filter (2 Units) |
: | 24 m² Cylindrical Body,Pressure Tube,Imported 4 cartridge filter |
| Command Cabin | : | 1 Unit, 2.4 x 3 x 2.5 m |
| Agitator | : | 2 m3 Capacity |
| Agitator Options | : | Single Shaft Type,planet type,pan type,double shaft type |
