MILLIENIUM BULKER

TANK CONSTRUCTION :

Tank is “MILLENIUM” shape and discharging is from bottom. Tank is built chrome  -nickel with thickness of 4mm . Working pressure 2 bar and test pressure 3 bar .,2 unit air pressure manometer . 4 “ discharging system and 6 mt special alloy discharge hose and 1 unit regulated to  2.5 bar safety valve nad Upper catwalk  and Access ladder is set to trailer

AXLE :

It has a carrying capacity of 3x12 tons and donated with an automatic adjusting break lever.NURSAN BRAND

AIRCOMPRESSOR :

3 head with 2 cylinder 32 HP diesel-electric NURSAN brand  air compressor(OPTIONAL)

   BRAKE SYSTEM :

 Brake is designed in accordance with the European standards. WABCO-HALDEX products are used as Equipments. Manuel break ratchets, break ventil, break bellows (30cm cylinder). There are two replaceable and protected break sockets in front of the trailer.

KING-PIN :

It is  made of forged steel (42 Cr Mo 4) which is coherent to 2”SAE/DIN” norms and durable against high level stretching and breakings. It can be replaceable via screw connections.

ELECTRICAL SYSTEM :

We have got 24 V electrical installment which is designed according to EU rules

There are stop lambs with many parts which consist of  reverse light and fog light on the trailer. There are 2 electrical sockets (24N/24S)   and an ABS socket on the front panel.

PAINT :

The surfaces are cleaned under high pressure with water and bonder chemical liquid. Then it is dyed with one coat of epoxy die, and a last coat of acrylic die. It is very durable against chemical effectiveness. As desired, colours can be chosen from the RAL codes.

GUARANTY  :

-         1 year spare parts ( manifactuarer guaranty )

-         1 year or 100.000 km NURSAN manifacture guaranty
