The Hair Dye Kits Packaging Machine is designed for automatic packaging of small to medium-sized square and rectangular boxes. This user-friendly machine allows operators to wrap boxes in an envelope-style package, ensuring a smooth and efficient operation. The machine is equipped with encoder-controlled PLCs, with settings and controls adjusted through a touch screen, making mold changes simple and convenient. It supports both manual and automatic feeding depending on the production line setup. For added convenience, an opening strip can be attached to the external foil for easy access. Optional features include a photocell system and date coding equipment, which can be integrated when using colored or printed foil on the outer layers of the boxes.
Technical Specifications
| Machine Dimensions |
H190 x W100 x L430 cm |
| Weight |
950 Kg / 1,100 Kg |
| Feeding Belt Dimensions |
H90-100 x W25-30 x L140-150 cm |
| Power |
3.5 kW, 380/400 VAC 3 Phase 50/60 Hz |
| Air Consumption |
6 bar / min |
| Noise Level |
70-80 Decibels |
| Capacity Per Minute |
20-40 Units Depending on Product Volume |
Package Dimensions
| Length (A) |
Min: 50mm / Max: 320mm |
| Width (B) |
Min: 30mm / Max: 120mm |
| Height (C) |
Min: 20mm / Max: 80mm |
| OPP, BOPP, PVC Length - Mechanically Adjustable |
Min: 110mm / Max: 420mm |
