G-Mtk130 Mobile Tertiary Crusher-General Makina

G-MTK130 Mobile Tertiary Crusher is one of our only chassis facilities and can be towed with a single TIR. It has been the choice of many enterprises with its special design and high performance.



Feeder System and Hopper:

The feeder system can be preferred with a conveyor belt to prevent sticking. In this way, trouble-free operation and minimum maintenance are provided. The feeder chamber is 8 m3.

It is one of the most ideal crusher plants for making sand on the sieve or unused products of mobile crusher plants.

The feeder hopper is also suitable for direct conveyor feeding from the plant with excavator and loader.



G-MTK130 Mobile Tertiary Unit

Rotor 1300 x 1200 mm

There is a row wall system that provides thinning in the crusher.

Engine Power 250 KW

Adjustment blocks are hydraulic system.

It is unique with its high reduction rates of up to 50x.

Main conveyor belt system 800 mm

Vibrating screen system high-capacity type

Size : 1600 x 5000 mm

Engine Power 15 KW 3-Storey

Under-sieve stock conveyor 600 mm folding type

Stock conveyor 2 pieces 600 mm folding type

Return collection conveyor 1 piece 500 mm

Return conveyor 2 pieces 500 mm

Mobile chassis system 2-axle special construction chassis

Hydraulic power system 125 liters

There are 6 hydraulic foot mechanisms in the hydraulic system, these feet are strengthened with 6 fixed feet after being locked.

Panel material is Siemens brand.

Drive drums are rubber coated and gear type.

Electric motors are of inter,gamak and emtaş brands.

Conveyor belt tires are Ovakent, Derby and Eksaş brands.

Bearings: SKF, NACHI or equivalent bearings.

The flat product used is Eregli Iron and Steel product and is of A1 quality.

The capacity is variable depending on the material to be broken, the feed and the final product dimensions and has a capacity of 200-300 tons.

Transport Dimensions: Width 3500 mm x Length 16.000 mm x Height 4500 mm

All of our products are CE certified by the European Union.
