FOTOSORTER Four Channel Color Sorter

Function :



Many food grain and seed crops need to separated by color which can effectively be done in an electronic  sorter utilizing optical lens or CCD Camera and compressed air jets to identify and discard and    particles that do not fit the color profile programmed   into the machine. These operate automatically and are extremely reliable.



AKY Color Sort optical color sorting machine separates the discolored kernel from good kernels   which have already pre-cleaned. Quality of screened product increases to %99,8. AKY Sorturk Color sorter machine constructed with latest technology available to the industry.



Work Principle :



An elevator feeds kernels into hopper which is located   on top of the color sorter. From hopper kernels fed in   to machine from 3 channels out of four. Kernels flow downwards as a thin layer passing by in front of CCD cameras. These cameras detect the discolored kernels, kernels that are low quality. CCD cameras send commands to computer program and program converts the commands for ejectors to separate these kernels  from the good kernels. These low quality kernels fed back in to the system from the last channel and discolored kernels re-sorted by color sorter. This way, product wastage reduces.



CCD cameras can detect discoloration on a kernel as small as 0,008 mm2. Machine is programmable for product quality variations. Integrated computer    program alerts of faults and errors that machines can come across whilst operating.
