Fixed Type Concrete Batching Plants
Price :
Ask For Price
Ad Code :
M-157046
Ad Type :
For Sale - New
Views :
482
Date Updated :
26 Aug 2023
Production Type :
Brand
Brand
ins makina
Model :
INS BS 120 BS
Production Year :
2017
İns Makina Beton Santralleri
Türkiye - Ankara - Yenimahalle
Turgut Özal Mah. 1940. Cadde, No:81/31
Ad Description
FIXED CONCRETE BATCHING PLANTS
(35-60-100-120-135-150-180-240 m3/h capacity)
120 m³ /h CAPACITY CONCRETE BATCHING PLANTS
Technical Specifications
| Aggregate Bunker | : | Tanks: 4x30 m3 Total Volume : 120 m3 |
| Cement Silo | : | Capacity: 100 tons – 2 unit (Can optionally be bolted.) |
| Cement Spiral Conveyor | : | 2 Unit, Size : Ø 273 mm x 12000 mm WAM |
| Cement Silo Equipments | : | Upper and Lower Level Meters WAM |
| Aggregate Weighing Machine | : | 6 m3 Load cell : 4 x 5000 kg, ZMC(HOLAND) |
| Transit Mixer Loading Band | : | Size : 1 Unit 1000 x 29000 mm |
| Cement Weighing Tank | : | Weighing Capacity : 1700 kg , Load Cell : 1000 kg , ZMC(HOLAND) |
| Water Weighing Tank | : | Weighing Capacity : 1000 kg , Load Cell : 1000 kg , ZMC(HOLAND) |
| Additive Tank | : | Weighing Capacity : 50 kg , Load Cell : 100 kg , ZMC(HOLAND) |
| Air Valves Board | : | MAG, Compressr 600 LT Volume, |
| Concrete Plant Automation | : | Tekno Automation |
|
Silo Top Filter (2 Units) |
: | 24 m² Cylindrical Body, Pressure Tube, Imported 4 cartridge filter |
| Intermadiate Loading Bunker | : | Capacity: 3 m3 |
| Agitator | : | 3 m3 Capacity |
| Agitator Options | : | Double Shaft Type |
| Command Cabin | : | 1 Unit, 2.4 x 3 x 2.5 |
