Dry Type Concrete Batching Plant 60 M3 Capacity 2 Years Warranty

Price : Ask For Price
Ad Code : M-445605
Ad Type : For Sale - New
Views : 12
Date Updated : 17 Jul 2024
Production Type : Special Production
Brand : Constmach
Model : Drymıx-60
Production Year : 2024
1
year
CONSTMACH Konkasör Tesisi ve Beton Santrali
Türkiye - İzmir - Kemalpaşa
Halilbeyli Bayosb Anadolu Cad. No:1 Bağyurdu Organize Sanayi Bölgesi Kemalpaşa / İzmir / TÜRKİYE
Ad Description

Dry Type Concrete Batching Plant For Sale - Call Us 24/7

Discover the DryMix-60 dry type concrete batching plant, offering a superior production capacity of 60 m³/h, efficiently and effectively supporting your workflow in the industry. Weighing 27 tons and designed without including a cement silo, it facilitates installation and transportation processes. With a total motor power of 55 kW and a required electrical generator capacity of 80 kVA, it provides the energy needed for continuous and reliable performance. The DryMix-60, requiring only a 200 m² working area, saves space and allows you to make the best use of your business’s existing space.

The technical specifications of the DryMix-60 include four 15 m³ aggregate storage bunkers, a 1.5 m³ aggregate weighing bunker, and an aggregate weighing conveyor measuring 600 x 9,700 mm, offering top-level precision in raw material management. A 600 kg capacity cement weighing bunker, a 300-liter water weighing bunker, and a 30-liter additive weighing bunker maintain the accuracy and consistency of your mix. A 300-liter capacity air compressor ensures continuous and uninterrupted workflow. Cement silo options ranging from 50 to 500 tons adapt to projects of every scale.

Equipped with a fully automatic control system, the DryMix-60 maximizes operational efficiency and features a user-friendly interface that operators of all levels can easily use. These superior features make the DryMix-60 suitable for use in any setting, offering a wide range of applications. Whether you are looking for an entry-level investment or want to expand your existing capacity, the DryMix-60 is an excellent choice. It offers the opportunity to grow your business and quickly bring your projects to life.

DryMix-60 Dry Type Concrete Batching Plant Technical Specifications

GENERAL FEATURES

  • Production Capacity: 60 m³/h
  • Weight: 27 tons (excluding cement silo)
  • Total Motor Power: 55 kW
  • Required Electrical Generator: 80 kVA
  • Space Required for Operation: 200 m²

TECHNICAL SPECIFICATIONS

  • Aggregate Storage Bunker: 4 x 15 m³
  • Aggregate Weighing Bunker: 1.5 m³
  • Aggregate Weighing Conveyor: 600 x 9,700 mm
  • Cement Weighing Bunker: 600 kg
  • Water Weighing Bunker: 300 liters
  • Additive Weighing Bunker: 30 liters
  • Air Compressor: 300 liters, 4 kW
  • Cement Silo: Capacity options from 50 to 500 tons
  • Control Type: FULLY AUTOMATIC
