Automatic Double Column Band-Saw,D-O 550

Description

Fully automatic Linear Way for cutting solid stocks, tubes and profiles of steel, cast-iron light and nonferrous material for cutting at only 90°. Complete steel fabricated. The rear jaw contains a number of hardened rollers driven through a worm and wheel by an electric motor. The front vice consists of a number of free running rollers. A limit switch assembled on top the vice stops the machine when the block is exhausted. Once the workpiece is clamped between the rollers no further clamping is needed. The work is fed through the vice to the bar stop which contains a micro-switch controlling the bar feed motor. A piece counter controls the number of the cuts. The machines stop automatically at the blade breakage. The machines are fitted with a removable coolant tank incorporating a submerged electric coolant pump which supplies coolant to both guide assemblies. Bi-Metal saw blade, Chips Conveyor and 1,2 meters in feed roller table are supplied as standard.

Technicial Specifications
