9 CRUSHING PLANT SALE TURBO DRAGON MACHINE

Mobile: 0555842 86 86

DRAGON 9 Mobile Closed Circuit Crushing and screening plant new technologies

Dragon 9 Closed-circuit crushing system

All systems were collected on a single platform , with 1 GB portable. Designed to be in operation within 15 minutes of edilmişd .

Classic Rock Crusher plants alone more you can do with jobs . Current world and Turkey, the construction of our most preferred in the market .

Machines and equipment available in the system

* Vibrating Feeder and Hopper Feeder system

Feeder Dimensions : 800 x 3000 mm

2 Piece with vibrators is sağlanmakd high vibration . In this way, works smoothly and is sunulmakd minimum maintenance .

Excavators and Loaders feed hopper feeder is suitable for permanent Kamyonla feeding studies done with extra compartment .

Feeder wear points are korunmakd with interchangeable wear armor .

Tray feeders are in the playoff system . By-pass conveyor eliminated thanks to the stockyard earth materials spill.

* Dragon 9 Advanced Turbo Impact Crusher System

Feeding trough 850 x 800mm

Rotor: 1100 x 800mm Crusher provides the caret has 2 special wall .

Engine Power 110 kw custom settings through blocks of primary , secondary one machine function ? ? Also were collected.

Up to 50 times with high reduction ratio is unsurpassed.

* Main Conveyor Belt System is 800 mm Crawler wheel conveyors .

* Vibrating Screen Systems High Capacity Type

Size : 1300 x 4000mm

Engine power 11 kW Floors: 3 Floor

* Screen Conveyor 800 mm Folding -type six- Stock

* Stock Conveyor 600 mm Folding type 2

* Return Conveyor Collection 1 600 mm

* Return Conveyor 2 600 mm

* Mobile Chassis Chassis System 2 -axle private constriction

* The hydraulic system has 4 hydraulic foot mechanism , this kilitlendikd feet after six hard foot is strengthened.

2 for opening and closing the lift piston hammer has also the piston 6 is controlled by a special control system .

Hydraulic Power System 105 Litres

Magnetic Conveyor Belt 600 mm (optional )

* Board Material is branded Siemens .

* Soft Starter Panel Systems Abba in the system and special control system is available.

* Uzakd the Control ( Radio Control System ) is yapılabilmekd control of all functions .

Generator System is optional Cummins, Perkins, Doosan, Deutz 6 cylinder diesel engine brands and Marelli alternator . (Optional)

Capacity and supply material to be broken , which vary according to the size of the final product is 100 ? ? Capacity is 150 tons .

Tozsuzlandır System , Conveyor high-pressure water to suppress dust in the nozzle of the spray powder is blocked. (Optional)

Feeders would Vibromotorl Emtaş , Italvibras , Olin is Brand .

Main Belt Drive Pulley and Gear Type Rubber Coated is .

Electric Motors GAMAK , Emtaş , is International Branded .

Indirect special gear reducers 3 respectively.

Rubber Conveyor Belts are Brand Derby or Eksaş .

Bearings: SKF bearings or equivalent Eregli Iron and Steel flat products used item is not A1 quality .

* By-pass system (optional )

* Magnetic magnet (optional)

* Generator System (Optional)

* Truck addition which is used to make the feed hopper (Optional)

* Tozsuzlandır System ( Optional)

* Frequency Control System is used instead of soft starter . (Optional)

This system allows adjustment of the crusher operation cycle , thanks to these devices also work with Generators Demerajsız study , the selection of generators and low fuel consumption sağlanabilmektedir.takrib low fuel consumption of 19 - 21 liters / hour ( Optional)

** All of our products are CE certified European Union .

** Total Weight : 38,000 Kg

Transport ** Dimensions: Width x Height 3000 mm x 4300 mm Length 13000 mm
