• MINI CONTINUOUS CASTING MACHINE

1-DIMENSIONAL CAPACITY:

MAX.Ø40MM BAR, MAX.Ø30x2,00MM PIPE and MAX.30x8MM SHEET CAN BE PRODUCED BY CONTINUOUS CASTING BY MELTING GOLD-SILVER-COPPER or BRASS, Scrap or Ingot.

2-TECHNICAL SPECIFICATIONS:

MELTING CAPACITY: 3KG

INPUT VOLTAGE and FREQUENCY: 380V 50Hz

POWER: 8KW

FREQUENCY: 1-25KHz

METALS THAT CAN BE MELTED:

GOLD-SILVER-COPPER-BRASS

TEMPERATURE RANGE: 0°C to 1.150°C

PROTECTIVE GAS: NITROGEN or ARGON GAS

COOLING SYSTEM:

PURE WATER CIRCULATION CLOSED CIRCUIT CHILLER

COOLANT TEMPERATURE RANGE:

BETWEEN 18°C and 22°C

DIMENSIONS (WxLxHEIGHT-MM)

780x650x1511

WEIGHT: 230KG

BODY COLOR: MAY BE ORANGE OR BLUE.
