2 Button Single Speed Overhead Crane Remote Control
Price :
Ask For Price
Ad Code :
M-417763
Ad Type :
For Sale - New
Views :
131
Date Updated :
17 May 2023
Production Type :
Brand
Brand
Wieltra Vinç Kumandaları
Model :
Evo202
Production Year :
2021
Is Machine Revised? :
Yes
Wieltra Vinç Uzaktan Kumanda Sistemleri
Türkiye - Konya - Karatay
Büsan Organize Sanayi Bölgesi Fevziçakmak Mahallesi Medcezir Cad. No:8/B08 Karatay/KONYA
Ad Description
Remote control systems can be integrated with overhead cranes, gantry cranes, monorail cranes and all other systems.
As a result, we have sales all over Turkey, both during the initial installation and at the point of supplying the crane remote control that you are currently using but has failed.
Remote technical support is provided for the connection of these controls.
2 Button Single Speed Set
- Model : EVO202
- Button Speed : Single Speed
- Supply : 12V / 24V / 220V / 380V
- Production Year : 2021
- Origin : Turkey
Transmitter Unit General Features
- Operating Temperature Range: -35 to 80 C˚
- Plastic body structure: GFR
- Protection Class: IP65
- Weight (Including Battery): 325 Gr
- Low Battery Warning: YES
- Working Distance : 150 meters
- Radio Frequency Power: 10dbm
- Number of Channels: 80
- Command Response Time: 30 ms
- Average Battery Consumption: 8mA
- Dimensions: 180*60*46 mm
Receiver Unit General Specifications
- Operating Temperature Range: -35 to 80 C˚
- Plastic body structure: ABS
- Protection Class: IP65
- Weight : 1.35 kg
- Working Voltage: 180-230V AC 50 Hz
- Relay Contacts: 5A 250VAC/30VDC
- Dimensions: 210*123*56 mm
