Mtu 4000 Serıes Engınes

MTU 4000 SERIES MOTORS

Model: 16V 4000

Power Rating: 1940 kW @ 1500 RPM (3 units), 1600 kW @ 1500 RPM (1 unit)

Year of Manufacture: 2005 (3 units), 2007 (1 unit)



Manufacturer: MTU Friedrichshafen GmbH

HITEC INDUCTION CLUTCH UNITS



Type: XQ-ZNE094



Machine No.: 27805708-02



Design No.: Z0019



Manufacturer: HiTEC Power Protection BV (Netherlands)



Year of Manufacture: 2005



Outer Rotor Speed: 1500 RPM



Inner Rotor Speed: 4450 RPM



Inner Rotor Inertia Torque (MMOI): 94 kg m²



Weight: 5250 kg



DC Brake:

Torque: 12 kNm



Current: 420 A (DC)



Number of Poles: 12



Operation Type: S9



3 Phase Acceleration Winding:

50 Hz, 400 V, 11.5 A, Power Factor: 0.75, Duty: S1, 2 poles



Bearing and Lubrication:

Outer Bearings:



Generator Side: 6238M C3



Diesel Side: 6326M



Lubricant: Shell Gadus S5 V42P 2.5



Lubrication Interval: 4400 hours / 6 months, 50g/oil nipple



Inner Bearings:



Generator Side: NUP 2213 ECP C4



Diesel Side: NU 2213 ECP C4



Lubricant: Klüber Isoflex Topas NCA 51



Lubrication Interval: 4400 hours / 6 months, 100g/oil nipple



CONVERSION OPPORTUNITY

These DRUPS systems can be easily converted into high-capacity generator sets. Thanks to oversized alternators and robust MTU 4000 series engines, these units can be turned into powerful 1.75 MW standby generators. This offers high fuel efficiency and long maintenance intervals.
